Per-minute speeds of 39.9 m, 34.2 m, 30 m, 20 m and 15 m can be selected depending on media type and colour combinations Print data is processed at a resolution of 1,200 dpi x 2,400 dpi Tasks such as colour adjustments, colour registration control and calibration are fully automated with Intelligent Quality Care Operation is intuitive by following on-screen instructions; no need for extensive user training No pre-coating of media required Fifth colour station with white toner for even more print applications New Simitri® V toner technology for smooth processing and excellent print quality on a wide range of substrates
Brand
Konica-minolta
Models
| Technology | Dry Toner Electrophotography |
| Colour Resolution | CMYK, white (optional) |
| Tone Scale | Main scan: 1,200 dpi (3,600 dpi equivalent)Sub scan: 2,400 dpi (8 bit) |
| Paper Widths | 330 mm fixed (standard), 250 to 330 mm selectable(replacement of certain parts necessary) |
| Max. printed image width (length) | 320 mm (1,294 mm) |
| Media thickness (weight) | 76 to 270 μm (62 to 256 g/sqm) |
| Supported substrates | Paper, PP, PET (tack or non-tack, incl. textured paper, film etc.) |
| Printing speed | 39.9 m/min. (CMYK), down to 20 m/min. (CMYK+W),39.9, 34.2, 30, 20, 15 m/min. depending on media types |
| Machine dimensions (W x D x H) | 7,500 x 1,230 x 1,620 mm |
| Machine footprint (W x D) | 9,700 x 3,200 mm (incl. operating space) |
| Machine weight | 1,800 kg |
| Web control | Integrated web guide system (BST) on infeed section and rewinder |
| Max. roll diameter | 800 mm (unwinder and rewinder) |
| Shaft diameter | 3 inches (76 mm) |
| Konica Minolta Controller | IC-611 |
| Kodak (Creo) Controller, optional | IC-320L |
| Print engine | 3x 200-240 V, 25 A, 1-phase, 50-60 Hz |
| ICCU | 1x 200-240 V, 3 A, 1-phase, 50-60 Hz |
| Winders | 1x 200-240 V, 32 A, 1-phase 50-60 Hz (incl. 300 mA RCCB, Type A) |
| Compressed air | 6 bar, min. 20 l/min., 8 mm tube diameter |
